This is similar to a breadboard layout but with added potentiometers, spdt switches and sockets and made to solder instead of using jumper cables. For prototype purposes mostly for eurorack but can be used for other projects too! Potentiometers, spdt switches and sockets have their respective pins near them to solder a wiring cable or […]
3U to 1U and 1U to 3U Eurorack Adapters Converter Panel 4 types available with included nuts and screws. New updated look for 2021, old logo is gone. Please click here for information and ordering.
NASA soldering quality test Just a quick post to share this pdf. It’s quite old now but i think still very relevant and very useful to see how much different solder joints can look and how to do it properly. Download link: NASA Soldering Basics
Breadboard utility pcb’s I was getting crazy having the sockets drop off the breadboard all the time so i made theses. They all have 2.54 holes for standard female or male headers that are linked to their respective pins. The ones using the whole row from top to bottom of the breadboard have dedicated hole […]
Free 10hp blank pcb panel gerbers template Gerbers download zip file This site lets you compare prices from many pcb fab: https://pcbshopper.com/ If you want black, use soldermask black when you order. Silkscreen is usualy white. HASL is cheaper, it makes silver look for holes and labels if you use soldermask layer in pcb software for […]
EITHER WAY Modular Eurorack Power Cable Orientation It is very simple yet many ask about it. I understand the worry, modules are expensive but when you see “either way” under the power connector that means you can connect the power ribbon cable either way. There is a small IC (integrated circuit) at the right on […]
Note If there is no flat side marked on the pcb, just use a multimeter to find the ground. Usualy ground is the square pad = cathode. Now what if there is no flat side on the led, no flat side on the pcb silkscreen, build guide sucks and both pads on the pcb are […]
Air pump DIY Manual SMD Vacuum Pick And Place Tool for Eurorack Modular Synth Just a quick hack i did, i got the idea from this video : https://www.youtube.com/watch?v=qJWUUK1s_G0 I hope it can helps someone, it’s kinda faster if you have a lot to populate.
Modular synth tips and ideas I was cleaning some folders and saw this “The book of bad ideas V2.pdf” i saved from Muffwiggler forum a while ago. I’m sure some of you did not seen it yet. Many useful tips and such. The book of bad ideas V2 Contents 1.0 Tools & Techniques 1.1 […]
So first of all thanks to Stereoping for this tutorial i found on their site. I just wanted to add some of the challenges i went through, adjustments, etc… I started using sticker adhesive paper, super nice results but it’s paper… This method for toner transfer is easy but you have to do it right. […]
